Introduction to Shank Adapters

Shank adapters are used for transmitting power from the rock drill to the drill stems.

SHANDIKE Shank Adapter

Shank adapter is designed to transmit power from rock drill piston to extension drill rod and finally to drill bit. When deploying, one side of shank adapter is connected to drill rod, while the other side should be connected with coupling or extension drill. Shank adapter can be deployed for drilling duties in tunneling, construction, mining, quarrying, etc.

Parameters

• Thread type: R25, R28, R32, R35, R38, T38, T45, T51, etc.

• Diameter: 32mm-70mm

• Length: 273mm-885mm

• Applicable rock drill brand: Atlas Copco, Tamrock, Ingersoll Rand, Boart Longyear, Furukawa, Montabert, Soonsan, Everdigm, etc.

Features:

• Precision and reliability granted by premium material, fine CNC machining and heat treatment processes;

• Carburizing process is applied to promote surface hardness, ensuring better wearing quality.

Specifications：

Drilling works for blasting duties in tunneling, construction, mining, quarrying, etc.

	Rock Drill	Shank Adapters	Thread	Length (mm)
	Atlas Copco COP1036/1238/1038HB		R32 T38 T45	500 500 500
	Atlas Copco COP1432/COP1532/ COP1440/COP1838HD/ME		R32 R38 T38 R32 TC35 T38 R32 R35 R38 T45 T51	435 435 435 525 525 525 525 525 525 525 525
	Atlas Copco COP1440/COP1550/COP1838		R32 R38 T38 R38 T38 R32 TC35 R38 T38	435 435 435 455 455 525 525 525 525
	Atlas Copco COP1840EX/COP1850EX		T38 T45 T51	770 770 770
	Atlas Copco COP1840/COP1850		T45 T51	565 565
	Tamrock HL300		R32	400
	Tamrock HL500-45/510-45		R32 T38 T45	550 550 550
	Tamrock HLX5/HLX5T		R32 R38 T38 R32 T38 T45	500 500 500 575 575 575
	Tamrock HL650-45/700-45/700T-45/ 710-45/800T-45		T38 T45	600 600
	Tamrock HL1000/HL1010/HL1000S/ HL1010S-52		T45 T51 T45 T51	670 670 590 590
	Furukawa HD609		T38 T38 T45	620 690 620
	Furukawa HD612		T38 T45 T45	710 710 720
	Furukawa HD709		T38	620
	Furukawa HD712		T45 T51 T45 T51	590 590 790 790
	Montabert HC40		R32 R38	447 447
	Montabert HC80, HC120		T45	490
	Ingersoll-Rand URD475/URD550/VL120/ EVL130/VL140		R32 R32 T38 T45	330 380 380 380
	Ingersoll-Rand YH65/YH80		T38 T45	500 500
	Ingersoll-Rand YH65RP/YH70RP/ YH75RP/YH80RP		T38 T45	700 700
