The DTH hammer is a component of the DTH drilling tools and belongs to the working device of the DTH drilling tools. DTH hammer is divided into low air pressure DTH hammer, medium air pressure DTH hammer and high air pressure DTH hammer, which are used for blast hole drilling and water well drilling project.
The DTH hammer is a component of the DTH drilling tools and belongs to the working device of the DTH drilling tools. DTH hammer is divided into low air pressure DTH hammer, medium air pressure DTH hammer and high air pressure DTH hammer, which are used for blast hole drilling and water well drilling project.
High air pressure DTH hammer Feature
• High quality alloy steel materials, internal parts with heat-treated technology.
• With various shank hammer type: DHD/COP/QL/MISSION/SD
• With various hammer model: 3.5’’, 4’’, 5’’, 6’’, 8’’
• Using the latest rock drilling theory, optimizing the inside structure and the size of the air distribution, to make the DTH hammer obtain the optimal energy transfer and make it achieve faster drilling speed and lower air consumption.
• The check valve can be replaced to the one with bigger air controlling hole to provide more efficient cutting discharge.
• The top sub and the drive chuck have special thread, which can achieve an easier disassemble.
| DHD /COP DHD/COP SHANK HAMMER | |||||
| Model | 3.5” | 4” | 5” | 6” | 8” |
| Bit shank | DHD3.5/COP34 | DHD340/COP44 | DHD350/COP54 | DHD360/COP64 | DHD380/COP84 |
| Length without bits(mm) | 990/938 | 1045/1000 | 1214/1070 | 1300/1238 | 1522/1460 |
| Thread connection | API 2 3/8” REG PIN | API 2 3/8” REG PIN | API 3 1/2” REG PIN | API 3 1/2” REG PIN | API 4 1/2” REG PIN |
| Outside diameter(mm) | 80/82 | 98/99 | 126 | 142/146 | 180/183 |
| Bit diameter(mm) | 90-115 | 110-138 | 138-165 | 152/165-203 | 203-271 |
| Bit with foot valve | WITH/WITHOUT | WITH/WITHOUT | WITH/WITHOUT | WITH/WITHOUT | WITH/WITHOUT |
| Working pressure (bar) | 14/16-24 | 14/16-24 | 14/16-24 | 14/16-24 | 16-22 |
| Weight(kg) | 28/38 | 38/45 | 85 | 98/102 | 190/198 |
| MISSION MISSION SHANK HAMMER | |||||
| Model | 4” | 5” | 6” | ||
| Bit shank | M40 | M50 | M60 | ||
| Length without bits(mm) | 986 | 1108 | 1300 | ||
| Thread connection | API 2 3/8” REG PIN | API 3 1/2” REG PIN | API 3 1/2” REG PIN | ||
| Outside diameter(mm) | 98 | 120 | 142/146 | ||
| Bit diameter(mm) | 105-138 | 130-165 | 152/165-203 | ||
| Bit with foot valve | WITHOUT | WITHOUT | WITHOUT | ||
| Working pressure (bar) | 14-24 | 14-24 | 14-24 | ||
| Weight(kg) | 38 | 83 | 98/106 | ||
| QL DHD SHANK HAMMER | |||||
| Model | 5” | 6” | 8” | ||
| Bit shank | QL50 | QL60 | QL80 | ||
| Length without bits(mm) | 1066 | 1224/1238 | 1460 | ||
| Thread connection | API 3 1/2” REG PIN | API 3 1/2” REG PIN | API 4 1/2” REG PIN | ||
| Outside diameter(mm) | 120 | 138/146 | 180 | ||
| Bit diameter(mm) | 138-165 | 152/165-203 | 203-271 | ||
| Bit with foot valve | WITH | WITH/WITHOUT | WITHOUT | ||
| Working pressure (bar) | 14-24 | 14/16-24 | 16-22 | ||
| Weight(kg) | 85 | 87/102 | 198 | ||
